Vanner IQ Series - Specifications Figure 1 Specifications

Specifications
- 6 - IQ SERIES OWNERS MANUAL
1.2 Specifications Figure 1 Specifications
Model Numbers
SPECIFICATIONS
IQ12-2600
IQ12-3600
IQC24-3600
IQC12-2600
IQC12-3600
AC Output Power
Continuous
2600 Watts
3600 Watts
3600 Watts
Surge (3 sec ) amps
65 Amps
80 Amps
80 Amps
Output Voltage - All Models
120 Volts +/- 5%
Output Frequency - All Models
60 Hz +/- 0.1 Hz
Output Waveform - All Models
Modified Sine Wave
DC Input Voltage Range
10.5 - 16.0 VDC
21.0 - 32.0 VDC
DC Input Current at no load
Inverter OFF
60 ma
60 ma
Inverter ON in Load Demand Mode
160 ma
160 ma
Inverter ON - Load Demand OFF
1.8 amps
AC Output Wiring Method
All IQ Models (inverter only)
1 GFCI Duplex Receptacle
All circuits are breaker protected
1 - 15 amp output terminal
1 - 20 amp output terminal
1 - 30 amp output terminal
All IQC Models (inverter/charger)
1 GFCI Duplex Receptacle
All circuits are breaker protected
1 - 30 amp output terminal
AC Input Wiring Method
All IQC Models (inverter/charger)
1 - 30 amp input terminal for charging and feedthrough
All circuits are breaker protected
1 - 30 amp input terminal for optional feedthrough only
Battery Charger (IQC Models)
Charging Output Current
120 amps
60 amps
AC Input current
Proportional to 30 amps 120VAC input @ 120 amps 12 volt output
WET Bulk Charge Voltage
14.4 vdc
28.8 vdc
WET Float Charge Voltage
13.2 vdc
26.4 vdc
GEL Bulk Charge Voltage
14.1 vdc
28.2 vdc
GEL Float Charge Voltage
13.6 vdc
27.2 vdc
AC Input Voltage Tolerance for Transfer Switch
Low Input Voltage Switchover Value
90VAC or 77VAC (Selectable)
AC Input Voltage
120 VAC + 12 volts / - 30 or -43 volts (selectable)
AC Input Frequency
60 Hz +/- 5 Hz
Transfer Switch transfer time
30 ms
System
Ambient Temperature
Continuous output at -40 to +105 degrees F (-40 to +40 degrees C)
Cooling Air
Thermostatically controlled exhaust fan
Enclosure
White painted aluminum with non-corrosive hardware
Dimensions All Models
8.4"H x 17.5"W x 14.0"D
Unit Weight
60 Ibs
75 lbs
75 lbs
