Accessories
IQ SERIES OWNERS MANUAL - 9 -
Remote Control Panel D08514
D07934 Remote APM Panel D07934 Remote APM Panel
built before Inverter/Charger built after Inverter/Charger
serial number 02154-049638 serial number 02154-049638
Remote APM (Automatic Power Management) Panel D07934
The optional Remote APM Panel, part number D07934, is designed for use with Inverter/Charger Models
IQC12-2600, IQC12-3600 and IQC24-3600.
Label Clarification: The D07934 Remote APM Panel has been built with two different labels.
The label was updated to show APM values for IQC Inverter/Chargers effective serial number
02154-049638 (June 3, 2002). APM values selected by the Remote APM Panel are
determined by the IQC inverter/charger serial number regardless of the APM Panel label.
Inverter Power System
INVERTER
BATTERY LOW
OVER TEMP / OVER LOAD
CHARGER-BULK
CHARGER-FLOAT
ON
OFF/RESET
INCORPORATED
R
