Setpoint Range
The SETPT RANGE sub menu defines the Maximum and Minimum temperatures allowed in the
HEAT and COOL modes. Adjusting these temperatures limits the temperature ranges allowed
when setting Setpoint temperatures.
Equipment Type
WARNING: The thermostat must be configured correctly to match the equipment type. The number
of cooling and heating stages must be defined in the Conventional or Heat Pump setting.
For Heat Pumps, the reversing valve operation must also be defined as ON in HEAT or ON in
COOL. The Reversing Valve is default to On in Cool.
Equipment Settings
Conventional Systems
You must enter an Installer Password to access the EQUIPMENT SETTINGS from the Main Menu.
The following settings can be changed for Conventional Systems:
DEFAULT OPTION
MIN ON/OFF TIME 3 MIN 1-6 MIN
Minimum cycle time for the furnace/air conditioner.
FAN ON IN HEAT YES NO
(this option only applies
to the furnace)
The fan turns on when the
thermostat sends the fan on
signal. The thermostat controls the
fan. Fan must be in AUTO mode.
The furnace waits until enough heat is
built up before turning on the plenum
fan. The furnace controls the fan. Fan
must be in AUTO mode.
