Product Specifications
Specifications Vantage Communicating Thermostat
Model STAT
Power Input 20-30 Vac (24 Vac nominal), 60/50Hz
Power Draw Typical 9.80 mA rms – This value is with 24 VAC input voltage and backlight OFF
Power Draw Maximum 36.40 mA rms – This value is with 18 VAC input voltage and backlight ON
Rated Output Current 0.001 A to 1 A continuous per output with up to 5 A surge (half cycle)
Typical Control Accuracy ± 1°F at 68°F / ± 0.5°C at 20°C
Dimensions HWD 4.85” x 3.875” x 1” / 123.2mm x 98.4mm x 25.4mm
Weight 6.9oz / 195.6g
