MENU SYSTEM : MAPPING
4
02.9673.0001 A 22-May-01 67
Stor Store Cue
Stores cue by number. Cue number stored is dependent on next cue ID
in cue list since this field is not editable.
Str Strobe Specifies strobe function for manual control.
Strk Strike Displays total number of lamp strikes.
STST Sensor Test Indicates that a system sensor test is in progress.
SWAP Swap
Swaps pan and tilt functions for special focus requirements such as
moving mirror mechanisms.
Test System Tests Accesses diagnostic tests for internal mechanisms.
Tilt Tilt
Specifies tilt function for manual control (Man) or tilt encoder for testing
(Test).
Time Timing Data
Allows manual setting of timing values for dimmer/intensity, focus,
color, and beam.
Ver Version Displays current software version (in two pages).
VIRT Virtuoso console Sets starting address for luminaire in Virtuoso systems.
Whl1 Wheel 1 (Color) Specifies wheel 1 for manual control or testing.
Whl2
Wheel 2 (Fixed
Gobo)
Specifies wheel 2 for manual control or testing.
Zoom Zoom Specifies zoom function for manual control or testing.
Table 3: Menu Function Definitions (Continued)
Display Definition Purpose
