VARI❋LITE - VL2200 SERIES SPOT LUMINAIRE USER’S MANUAL
66 22-May-01 02.9673.0001 A
LOFF Lamp is Off
Configures arc luminaire so that lamp will await manual command
before striking.
Man
Manual Com-
mands
Accesses functions for controlling luminaire mechanisms and timing by
entry of an absolute data value.
Mod Modify Cue Accepts cue number of cue to modify from cue list.
MODE DMX Mode
Accesses functions for setting DMX mode to standard or enhanced 8-bit
or 16-bit.
Modl Model Displays model number of luminaire. For example, 2413 (VL2413).
Move Move
Enables and disables pan and tilt movement and auto-correction.
MSEQ Master Sequence
A sequence playback mode which will replay the cues from the master
luminaire.
NoPg No Program Indicates that there is no software present in the luminaire.
OFF Off Turns off a function.
OK Okay Indicates that luminaire is ready to accept commands.
OK? Okay? Prompt for pressing [Enter] before an action is executed.
ON On Indefinitely
Sets Menu Display to stay on until programmed otherwise (DisP), turns
on a function, or turns on a menu item.
P UP Lamp Power Up Accesses options for lamp power up: on, off, or after calibration.
P/T Pan/Tilt
Accesses pan and tilt options for DMX function, system configuration,
and testing.
Pan Pan
Specifies pan function for manual control (Man) or pan encoder for test-
ing (Test).
PASS Test Pass Indicates that sensor test has passed.
PCue Play Cue Accesses cue list for play back of cues by number.
POWR Lamp Power Accesses function to turn lamp on or off.
PSEQ Play Sequence Plays back cue sequence. Press [Enter] to start and [Menu] to stop.
RDef Reset Default Resets default system configuration values.
RGob Rotating Gobo Tests rotating gobo wheel.
RHrs Reset Lamp Info
Resets lamp hour and lamp strike counters. For use when new lamp is
installed.
RTST Run-Test Indicates that a system mechanism test is in progress.
Sens Sensors Accesses sensor choices for diagnostic testing.
SEQ
Sequence Play-
back
Sets sequence playback mode to Individual (plays cues from each lumi-
naire) or Master (all luminaires play same cue).
STAT
Status/Error Dis-
play
Allows scrolling through error list or displays OK if no errors.
Table 3: Menu Function Definitions (Continued)
Display Definition Purpose
