3-2
Special Keys
Enter
Used to terminate the entry of a numeric or menu item selection.
It also serves as a scroll down key when selecting the Method
parameter setting.
Used to scroll up within the Method Parameter setting. Also used
to toggle the current motor selection and place the Archon in
“SYSTEM HOLD.”
Acts as a “backspace key.” Allows erasure of the current value of
any data entry item.
4,
6,
8,
2
These keys have dual functions. They are numeric as well as
directional keys. These keys are used to scroll up or down for
menu selection and operation of motors in “System Calibration.”
—
This is an Escape Key. It can be used to exit a menu.
