System Setup
03-914642-00:6
6-15
DesbDrn Pol. Desorb Drain Polarity This is at the Desorb mode on the
concentrator. This sets the input
signal from shorted (Normally
Closed), to an open (Normally Open)
position.
STOP Pol. Stop Polarity Incoming signal used for the
Emergency Stop. This sets the input
signal from shorted (Normally
Closed), to an open (Normally Open)
position.
Equib. Count Equib. Count This will set the number of positions
to be used in the Equilibrium section
of the Archon.
Equib. Time Equilibrium Time The minimum time the sample will
remain in the Equilibrium section to
reach ambient temperature
The “2
” and “8
” keys will step the brackets to the next menu line. The
numeric keypad is used to change numeric value settings, the “4
” and “6
”
keys are used to toggle from “Open” to “Closed” on signal polarity settings. The
ENTER key will accept the value and toggle to the next line.
Default Operation Value Table
Parameter Factory Default Value Range Allowed
Upper Soil Probe Temp 110
C amb-250
C
XFER Line Temp 110
C amb-250
C
Upper Soil Valve Temp 95
C amb-132
C
Gripper Open: 750 0-999 milliseconds
Gripper Closed: 999 0-999 milliseconds
Standby Pol. CLOSED CLOSED/OPEN
DesbDrn Pol. CLOSED CLOSED/OPEN
STOP Pol. CLOSED CLOSED/OPEN
Equib. Count 0 0-5
Equib. Time 0 0-999
