Inquiry function
Command Acknowledgement
Description
FREEZE MODE
Get
i:75 i:75aa
data length 2 characters
aa 00 = disabled (valve not frozen)
01 = enabled (valve frozen)
This function returns the actual freeze mode of a valve. It is normally used in combination
with the Fehler! Verweisquelle konnte nicht gefunden werden. command (refer to
«Fehler! Verweisquelle konnte nicht gefunden werden.»).
CLUSTER VALVE
STATUS
Get
i:93ab i:93abcdefghij
data length 42 characters
a high byte of cluster valve address in hexadecimal notation (0
hex
to F
hex
)
b low byte of cluster valve address in hexadecimal notation (0
hex
to F
hex
)
cccccc actual plate position (notation depending on communication range)
dddddd position offset (min. -30000, max. +30000)
eeee valve speed (min. 0, max. 1000)
f freeze mode (0 = disabled (not frozen), 1 = enabled (frozen))
g access mode (0 = local, 1 = remote, 2 = locked remote)
h control mode (1 = synchronization, 2 = POSITION CONTROL, 3 = CLOSED
4 = OPEN, 5 = PRESSURE CONTROL, 6 = HOLD , 7 = LEARN
8 = INTERLOCK OPEN by digital input 9 = INTERLOCK CLOSED by digital
input,C = power failure, D = safety mode, E = fatal error
iiiiiiiiiiiiiiii warnings (0 = no warning, 1 = warning present), i0 = service request,
i1 = parameter error, i2 = PFO not ready, i3 = compressed air failure,
i4 = sensor factor warning, i5 = reserved, i6 = offline, i7 = reserved,
i8 = ROM error, i9 = no interface found, i10 = no ADC, i11 = no ADC signal
on logic interface, i12, i13, i14, i15 reserved
jjjjjj 000000
This function returns the status information of an individual valve in the cluster. This
command is implemented on the master valve only and must not be used in combination
with the Fehler! Verweisquelle konnte nicht gefunden werden..
Example:
[i:9303] [CR][LF] Status inquiry of valve with address 3.
Answer: [i:9303012345-0250010001120010000000000000000000] [CR][LF]
valve address 03
actual position 012345 (range 0 to 100000)
position offset -2500
valve speed 1000
freeze mode 1 (enabled = frozen)
access mode 1 (remote)
control mode 2 (position control)
warnings 0010000000000000 (PFO not ready)
