VAT 642 Series - Page 72

INSTALLATION Series
642
72/119 Edition 2017-11-24 742280ED
Setup function
Command Acknowledgement
Description
FREEZE MODE
Set
c:75xx c:75
Get
i:75
i:75xx
data length 2 characters
aa 00 = disable freeze mode (valve will follow master valves plate position)
01 = enable freeze mode (valve will stop moving)
02 = enable freeze mode and move to close position
03 = enable freeze mode and move to open position
This function can be used to independently control an individual valve in the cluster. The
command must be used in combination with the Fehler! Verweisquelle konnte nicht
gefunden werden. command only.
Example:
G:03c:7502 Enables freeze mode and closes valve with address 3
Answer: G:03c:75
CLUSTER POSITION
OFFSET
Set
c:74abbbbb c:74
Get
i:74 i:74abbbbb
data length 6 characters
a sign (+ or -), 0 has equal function as +
bbbbb offset value, 0 ... 30000 (0 to 30% of full stroke)
This function adds or subtracts the offset value from the actual plate position that is
received from the master valve. It is available on slave valves only.
