Failure Check Action
- Sensor(s) connected? - Refer to «2.6 Electrical connection».
- 2 sensor version ?
650 . . - . . .
E - . . . .
- Verify configuration.
- Refer to «3.10.1 Pressure control operation with 2
sensors».
- ZERO done? - Perform ZERO when base pressure is reached. Refer to
«3.6.3 ZERO» for details.
Pressure reading is wrong
or
pressure reading is negative
- Does sensor power supply
provide enough power for
sensor(s)?
- Verify sensor supply voltage.
- Valve in open position, check
for O on display?
- OPEN VALVE and bring chamber to base pressure before
performing ZERO.
ZERO does not work
- ZERO disabled? - Enable ZERO.
Refer to «3.6.2 Valve and
sensor configuration» for
details.
- Sensor voltage shifting? - Wait until sensor does not shift any more before
performing ZERO.
- System pumped to base
pressure?
- OPEN VALVE and bring chamber to base pressure before
performing ZERO.
Pressure is not ‘0’ after ZERO
- Sensor offset voltage
exceeds ±1.4V
- Replace pressure gauge.
- Safety mode active, check for
D on display?
- Provide power to motor to allow for operation.
- Refer to «2.6 Electrical connection» for details.
- PRESSURE CONTROL
selected, check for P on
display?
- Select PRESSURE CONTROL mode.
Refer to «3.10 Pressure control» for details.
PRESSURE CONTROL does not
work
- LEARN done? - Perform LEARN.
Refer to «3.6 Setup procedure» for details.
- Setup done completely? - Perform «3.6 Setup procedure» completely.
- LEARN done? - Perform LEARN.
Refer to «3.6.4 LEARN» for details.
- ZERO performed before
LEARN?
- Perform ZERO then repeat LEARN.
Refer to «3.6 Setup procedure» for details.
- LEARN interrupted? - Repeat LEARN.
Refer to «3.6.4 LEARN» for details.
- Was gas flow stable during
LEARN?
- Repeat LEARN with stable gas flow.
Refer to «3.6.4 LEARN» for details.
- Tuning done? - Tune valve for application.
- Refer to «3.10.2 Tuning of control performance» for details.
- Is sensor range suited for
application?
- Use a sensor with suitable range (controlled pressure
should be >3% and < 98% of sensor full scale).
PRESSURE CONTROL not optimal
- Noise on sensor signal? - Make sure a shielded sensor cable is used.
If you need any further information, please contact one of our service centers. You can find the addresses on our website:
