9. Product Specifications
EzRay Air Wall (VEX-S300W) User Manual 51
ENGLISH
Item Item Dimension (mm)
Weight
(kg)
Total Assembly
(including
Power Box
Assembly and
X-ray Generator
Assembly)
With
Horizontal
Arm:
With
Scissor
Arm:
- -
900mm
Folded 1205.3(L)x1074.9(H)x342.6(W)
17.9
Unfolded 2468.3(L)x507.6(H)x342.6(W)
600mm
Folded 905.3(L)x1074.9(H)x342.6(W)
16.6
Unfolded 2168.3(L)x507.6(H)x342.6(W)
450mm
Folded 755.3(L)x1074.9(H)x342.6(W)
15.9
Unfolded 2018.3(L)x507.6(H)x342.6(W)
Total Arm
Assembly
With
Horizontal
Arm:
With
Scissor
Arm:
- -
900 mm
Folded 1077.0(L)x892.6(H)x58.4(W)
11.45
Unfolded 2338.7(L)x327.0(H)x58.4(W)
600 mm
Folded 777.0(L)x892.6(H)x58.4(W)
10.6
Unfolded 2038.7(L)x327.0(H)x58.4(W)
450 mm
Folded 627.0(L)x892.6(H)x58.4(W)
10.15
Unfolded 1888.7(L)x327.0(H)x58.4(W)
Horizontal Arm
Assembly
900 mm 976.0(H) x 151.2(V) x 58.3(W) 3.65
600 mm 676.0(H) x 151.2(V) x 58.3(W) 2.8
450 mm 526.0(H) x 151.2(V) x 58.3(W) 2.35
Scissor Arm Assembly 797.6(W) x 184.0(L) x 58.4(H)
7.8
Power Box Assembly 287.8(W) x 238.0(L)
3.1
X-ray Generator Assembly 325.0(W) x 299.5(L) x 222.7(H)
2.4
X-ray Beam Limiting
Device
X-ray
Beam
Area
(mm)
Round type
FOV: < ⌀ 60
0.013
Rectangular
type
FOV: 20 x 30 (30 x 20),
40 x 30 (30 x 40)
0.040
SSD(Source to Skin
Distance) (mm)
Min. 200 -
