9. Product Specifications
52 EzRay Air Wall (VEX-S300W) User Manual
9.2 Technical Specifications
X-ray Generator
Item Description
High Voltage
Generator
(Assembly)
Model
DG- S0102V1
Rated output power Max. 0.2 kW
Duty Cycle
1:60 or more
(Exposure time: Interval time)
Cooling Protection Thermistor ≥ 65 °C
Inherent Filtration 1.8 mm Al / 65 kV
Total Filtration Min. 1.5 mm Al
Type Inverter Type
Tube Voltage 55-65 kV
Tube Current 1.0-3.0 mA
X-ray Tube
Manufacturer VATECH Co., Ltd.
Model V1-650304 (Stationary Anode type)
Version 2.0
Focal spot size 0.4 mm (IEC 60336)
Anode heat contents Max. 2.7 kJ
Maximum Anode Heat
Dissipation
200 W
Target Material Tungsten
Target Angle 12.5°
Inherent Filtration Min. 1.5 mm Al
X-ray Coverage 70 mm at SID 200 mm
Tube Voltage Max. 65 kV
Tube Current Max. 3.0 mA
