Vatech GREEN SMART - Finishing the Scan; Checking the Captured Images

8. Acquiring CEPH Images (Optional)
Green Smart User Manual 101
ENGLISH
8.5 Finishing the Scan
1. Leave enough space between the Ear Rods.
2. Fold the Nasal Positioner up in case it’s unfolded.
3. Guide the patient out of the equipment.
8.6 Checking the Captured Images
Acquired images can be reconstructed and converted to DICOM format.
The exported images can be confirmed in EzDent-i / EasyDent.
Refer to the EzDent-i / EasyDent User Manual for more information.
1. The images are transferred to EzDent-i / EasyDent automatically.
2. The images are automatically saved if automatic save option is configured as default. If it
is not configured as default, click the Save button to save the images.
3. To check the image, double-click the one on the Patient List.
