9. Acquiring CBCT Images
Green Smart User Manual 103
ENGLISH
9. Acquiring CBCT Images
9.1 CBCT Imaging Program Overview
 Result Images
It provides conventional 3D CT sliced images.
 Image Acquisition Method
It acquires images with the X-ray beam scanning specific oral & maxillofacial regions and
reconstructs them to 3D sliced images.
 Examination Programs
It is classified as below based on the FOV.
Available
FOVs
(cm)
ROI Description
10x8.5
<Occlusion / Center>
 Covers both
maxillary and
mandibular
structures
including the 3
rd
molar region.
 Suitable for most
oral surgery
cases as well as
multiple implant
surgery.
10x7
<Occlusion / Center>
 For children aged
between 0 and
13.
 Covers both
maxillary and
mandibular
structures
including the 3rd
molar region.
 Suitable for most
oral surgery
cases as well as
multiple implant
surgery.
