14. Technical Specifications
138 Green Smart User Manual
Item Description
Weight
Without
CEPH unit
137 kg (302.0 lbs. – without Base)
190 kg (418.9 lbs. – with Base)
With CEPH
unit
162 kg (357.1 lbs. – without Base)
215 kg (474.0 lbs. – with Base)
Total Height
Without
Base
Max. 2304.5 mm
With
Base
Max. 2336 mm
Dimensions
during operation
(Length x Width x
Height)
Without
CEPH unit
1389.3 mm (L) x 1113 mm (W) x 2304.5 mm
(H) (without Base)
1389.3 mm (L) x 1113 mm (W) x 2336 mm (H)
(with Base)
With CEPH
unit
1390.3 mm (L) x 1882.3 mm (W) x 2304.5 mm
(H) (without Base)
1390.3 mm (L) x 1882.3 mm (W) x 2336 mm
(H) (with Base)
Rotating Unit Vertical Movement Max. 800 mm
Installation Type
Base Stand / Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box, CEPH Box (Optional), Base Box
(Optional)
14.1.2 Image Magnification
Mode FDD (mm) FOD (mm) ODD (mm) Magnification
PANO 600 477.7 122.3 1 : 1.25
CEPH 1745 1524 221.0 1 : 1.14
CBCT 600 428.6 171.4 1 : 1.40
 FDD: Focal Spot to Detector Distance
 FOD: Focal Spot to Object Distance
 ODD: Object to Detector Distance (ODD = FDD - FOD)
 Magnification = FDD / FOD
