7. Acquiring PANO Images
58 Green Smart User Manual
SPECIAL
Examination
N/A
TMJ LAT
Open / Close
An imaging mode to acquire a lateral
image of the TMJ, in which the X-ray
beam is directed on the lateral TMJ
region.
(TMJ Open and Close)
TMJ PA
Open / Close
(Optional)
An imaging mode to acquire a TMJ
image, in which the X-ray beam is
directed on the frontal TMJ, with the
patient's mouth open fully and close.
Sinus LAT
(Optional)
A special imaging mode to acquire a
Sinus image, in which X-ray beam is
directed on the lateral region of the
maxillary sinus.
Sinus PA
A special imaging mode to acquire a
Sinus image, in which X-ray beam is
directed on the frontal region of the
maxillary sinus.
**
Bitewing imaging mode is activated only when Orthogonal is selected in Arch Selection.
