⑨ Adjust the face of the patient so that it is balanced right and left, behind and front through
Horizontal Laser Beam.
For Sinus imaging, your face is up about 15 degree if the Horizontal Laser beam is
accurately located (See the following figure).
⑩ Adjust the Canine Laser Beam so that it is accurately located at the canine part of the patient.
1) Panoraic: position the Canine Laser beam at the canine.
2) Sinus: position the Canine Laser beam about 1 cm inside the wings of the nose.
3) TMJ: position the Canine Laser beam at the maxillary canine in case of Open.
Position the Canine Laser beam at the canine while mouth is closed in case of Close.
