9. Installing Software
112 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Initiating the Imaging Program
1. Click the Acquisition tab. The imaging mode selection menu appears in the left
pane (see below).
The imaging mode selection menu may differ due to your
equipment’s option (CEPH or non-CEPH) or the Display
option you selected in the setting menu.
2. Select an imaging mode from the menu. Based on your selection, the console
software window appears.
If the equipment is still in packing mode, the error code E001
appears. Go to 9.5.2 Setting Console Software > Disabling
the Packing Mode to disable packing mode.
3. Proceed to the section 9.5.2 Setting Console Software.
