10. Technical Specifications
122 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Item
Description
Weight
Without CEPH
unit
95 kg (209.4 lbs. – without Base)
135 kg (297.6 lbs. – with Base)
With CEPH unit
120 kg (264.5 lbs. - without Base)
160 kg (352.7 lbs. - with Base)
Total Height
Without Base
Max. 2292 mm
With Base
Max. 2320 mm
Dimensions during
operation
(Length x Width x
Height)
Without CEPH
unit
970 mm (L) x 1333 mm (W) x 2292 mm
(H) (without Base)
990 mm (L) x 1333 mm (W) x 2320 mm
(H) (with Base)
With CEPH unit
1905 mm (L) x 1333 mm (W) x 2292 mm
(H) (without Base)
1905 mm (L) x 1333 mm (W) x 2320 mm
(H) (with Base)
Rotating Unit Vertical Movement
Max. 700mm
Installation type
Base Stand / Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box, CEPH Box (Optional), Base
Box (Optional)
