3. Before Installing the System
34 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Part
No.
Items
Specification
Figure
QTY
Comments
Confirmed
(OK?)
24
Wrench Bolt
M10 x 25
w/ Spring and
Flat Washers
2
Yes □ No □
Wrench Bolt
M10 x 25
2
Yes □ No □
25
Wrench Bolt
M8 x 45
w/ Spring and
Flat Washers
4
Yes □ No □
26
Truss Bolt
M5 x 8
3
Yes □ No □
27
Truss Bolt
M4 x 8
10
Yes □ No □
28
Plate-
Switch/Recta
ngle One
Switch
C0000009
1
For domestic
only
Yes □ No □
29
Wrench Bolt
M8 x 20
w/ Spring and
Flat Washers
4
Yes □ No □
30
Set Screw
M10 x 20
4
Yes □ No □
31
Wall Plate
1
Yes □ No □
Terminal
Block 3 Pole
1
Yes □ No □
32
Blank
33
Up / Down
Switch
1
Yes □ No □
Up / Down
Switch
Holder
1
Yes □ No □
Double-Sided
Sticker
1
Yes □ No □
