3. Before Installing the System
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 35
English
Part
No.
Items
Specification
Figure
QTY
Comments
Confirmed
(OK?)
34
Ficher strong
anchor
M10 x 40
EAM8N
4
column
Yes □ No □
Wrench Bolt
M10-L20
w/ Spring
Washer
4
Yes □ No □
Ficher strong
anchor
M8 x 30
EAM8N
4
wall
Yes □ No □
Hex Bolt
M8-L15
w/ Spring
Washer
4
Yes □ No □
Wood Screw
M8 x 60
4
wall Wood
Yes □ No □
Wood Screw
M12 x 70
2
base
Yes □ No □
Wrench Bolt
M8 x 25 w/
Spring and
Flat Washers
2
wall Bracket
Yes □ No □
Nut
M8
2
wall Bracket
Yes □ No □
35
Wall Bracket
1
1
Yes □ No □
Wall Bracket
2
1
For America
only
Yes □ No □
