5. Installing the Equipment: Wall Mount
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 67
English
Drilling the Floor
1. Remove the aligning plate.
2. Drill the floor holes (size: 10.5 x 30 mm) by using the concrete hammer drill.
3. Remove the debris and clean the holes with the dust pump.
4. Put the Ficher strong anchor bolts into the holes and attach them with the
hammer. Verify that the Ficher strong anchor s are secured.
Ficher Strong Anchor
M10 x 40
(Part No. 34)
Hammer Drill
L = 200 mm (7.9”)
