2. Choosing an Installation Site
14 PaX-i Plus / Insight Installation Manual
Minimum Space Required
Without CEPH unit
2,200 mm (L) x 2,200 mm (W) x 2,600 mm (H)
With CEPH unit
2,200 mm (L) x 1,400 mm (W) x 2,600 mm (H)
If the ceiling height is less than 2300 mm (without Base) / 2320 mm
(with Base) (= max. height of the column + 100 mm), refer to
Appendix C. Limiting the Column Height
to lower the max.
height of the column.
Lead Thickness
≥ 1 mm
Width of the Entrance
The door of the X-ray room should have a clearance of more than 800 mm (31.5”) wide.
Floor Area
The floor of the X-ray room must be stable and level for system balance.
The floor must be able to support a minimum weight of 500 kg/m
2
(110 lbs / feet
2
)
Protection against Radiation
 To protect against radiation hazards, follow all federal and municipal requirements.
 During exposure, the operator should follow applicable radiation shielding
requirements and remain at least 2m (7’) from the source of the radiation.
 Maintain visible contact with the patient and a clear view of indicators such as the
warning lamp and imaging status on the PC.
