3. Before Installing the System
PaX-i Plus / Insight Installation Manual 27
Removing the Cover
1. Move the Main Box to a convenient place as close as possible to the installation
location.
2. Remove the Top Cover.
3. Remove a single side cover.
In case of unabling to lift the side cover up fully, due to ceiling
height, cut the box in half using the utility knife instead.
To Next Page
