3. Before Installing the System
28 PaX-i Plus / Insight Installation Manual
4. Put the PC System (Optional) down on the floor.
5. Separate two side EPS (A, B). The resulting view is as follows.
Do not discard thease EPS (A, B), so that they are reused later
when the CEPH unit is installed.
6. Separate two side EPS (A, B). The resulting view is as follows.
7. Remove the case column front cover
To Next Page
