3. Before Installing the System
PaX-i Plus / Insight Installation Manual 37
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
26
Truss Bolt M5 x 8
3 Yes □ No □
27
Truss Bolt M4 x 8
10 Yes □ No □
28
Plate-
Switch/Rectan
gle One
S it h
C0000009 1
For domestic
only
Yes □ No □
29
Wrench Bolt
M8 x 20
w/ Spring and
Flat Washers
4 Yes □ No □
30
Set Screw M10 x 20 4 Yes □ No □
31
Wall Plate 1 Yes □ No □
Terminal Blocl
3 Pole
1 Yes □ No □
32
Left Blank Intentionally
33
UP / DOWN
Switch
1 Yes □ No □
UP / DOWN
Switch Holder
1 Yes □ No □
Double Sided
Sticker
1 Yes □ No □
34
Ficher strong
anchor
M10X40
EAM8N
4
column
Yes □ No □
Wrench Bolt
M10_L20
W/Spring
Washer
4
Yes □ No □
Ficher strong
anchor
M8X30
EAM8N
4 wall
Yes □ No □
