Operating & Mounting instructions – 8 074 143.03/03 – Page 13
Operating
2nd Set Factory See
Parameter name Adjusting range default page
A203 2nd Base frequency 30...400 Hz 50 Hz 53
A204 2nd Maximum Frequency 30...400 Hz 50 Hz 53
F202 2nd Acceleration ramp 0,01...3600 s 30 s 53
F203 2nd Deceleration ramp 0,01...3600 s 30 s 54
A220 2nd Internal pre-set speed 0,00...400,0 Hz 0,00 Hz 54
A241 2nd Torque boost method selection 00 or 01 00 54
A242 2nd Manual torque boost setting 0,0...20,0 % 1,0 % 54
A243 2nd Manual torque boost frequency point 0,0...50,0 % 5,0 % 54
A244 2nd V/f characteristic setting 00 to 02 00 54
A261
2nd Frequency upper limit 0,00...400,0 Hz 0,00 Hz 54
A262
2nd Frequency lower limit 0,00...400,0 Hz 0,00 Hz 54
A292
2nd Second acceleration ramp 0,01...3600 s 15,00 s 55
A293
2nd Second deceleration ramp 0,01...3600 s 15,00 s 55
A294
2nd Method of second stage selection 00 or 01 00 55
A295
2nd Stage Acceleration change over point 0,00...400,0 Hz 0,00 Hz 55
A296
2nd Stage Deceleration change over point 0,00...400,0 Hz 0,00 Hz 55
b212
2nd Electronic overload setting 0,2...1,2 x IFIIN FU-INOM 55
b213
2nd Selection of electronic overload charact. 00 to 02 01 55
H203
2nd Motor kW rate 0,20...75,0 kW Default 55
H204
2nd Motor poles 2 / 4 / 6 / 8 4 55
H206
2nd Motor stabilisation constant 0...255 100 55
Analog outputs Factory See
Parameter name Adjusting range default page
C027
Function of FM PWM output 00 to 07 00 56
C028
Function of AM analog output 00 to 07 00 56
C029
Function of AMI analog output 00 to 07 00 56
b080
AM analog adjustment 0...255 180 57
b081
FM PWM meter adjustment 0...255 60 57
C087
AMI analog adjustment 0...255 50 57
C086
AM analog offset 0,0...10,0 V Default 57
C088
AMI analog offset 0,0...20,0 mA Default 57
Energy saving Factory See
Parameter name Adjusting range default page
A085
Operation mode selection 00 or 01 00 57
A086
Energy saving response 0,0...100,0 50,0 57
