Operating & Mounting instructions – 8 074 143.03/03 – Page 24
V/f characteristic
V/f
V/f
A041 Torque boost method selection VIC 00 or 01 00
Setting Function
00 manual boost
01 automatic boost
A042 Manual torque boost setting VC 0,0...20,0 % 1,0 %
A043 Manual torque boost frequency point VC 0,0...50,0 % 5,0 %
For applications which require higher starting torque, the standard starting torque can be increased.
Use parameter A041 to select between automatic and manual boost. Parameter A042 defines the
value by which the torque has to be boosted. The range in which this boost takes effect is defined by
parameter A043.
A044 V/f characteristic setting VIC 00 to 02 00
Parameter to set one of the possible V/f characteristics.
Setting Function
00 constant torque
01 reduced torque (Economy mode)
02 free adjustable V/f characteristic (b100...b113)
At manual boost, the torque is increased
between 0 Hz and 50 % of the base
frequency.
At automatic boost, this process depends on
the load.
Note:
Beware of overloading the
motor
