Overview of parameters
The following overviwe shows all parameters arranged according to their functions.
Display actual values Factory See
Parameter name Adjusting range default page
d001 Output frequency read only - 16
d002 Output current read only - 16
d003 Direction of rotation read only - 16
d004 PID controller feedback read only - 16
d005 Condition of digital inputs read only - 17
d006 Condition of digital outputs read only - 17
d007 Output frequency scaled read only - 17
d013 Output voltage read only - 17
d014 Output power read only - 17
d016 Operating hours motor read only - 17
d017 Operating hours inverter read only - 17
Base settings Factory See
Parameter name Adjusting range default page
A003 Base frequency 30...400 Hz 50 Hz 18
A004 Maximum frequency 30...400 Hz 50 Hz 18
F002 1st Acceleration ramp 0,01...3600 s 30 s 18
F003 1st Deceleration ramp 0,01...3600 s 30 s 18
F001 Output frequency 0,00...400,0 Hz - 18
A020 Internal pre-set speed if A001=02 0,00...400,0 Hz 0,00 Hz 18
A001 Method of speed command 00 to 05 01 19
A002 Method of run command 01 to 05 01 19
Operating & Mounting instructions – 8 074 143.03/03 – Page 7
