Operating & Mounting instructions – 8 074 143.03/03 – Page 91
Options
Technical Data
Filtertype >pDRIVE< CE-DR 400/28 CE-DR 400/56 CE-DR 400/68
for >pDRIVE< inverters CX profi 11 and 15 CX profi 18...30 CX profi 37
Mains connection
Phases 3 AC 3 AC 3 AC
Voltage 380...480 V ±10% 380...480 V ±10% 380...480 V ±10%
Nomina current 28 A 56 A 68 A
Overload 20 % for 60 s 20 % for 60 s 20 % for 60 s
Leakage current (maximum) 80 mA 80 mA 80 mA
Frequency 50...60 Hz ±5% 50...60 Hz ±5% 50...60 Hz ±5%
Ambient conditions
Ambient temperature 0°C...+40°C
Solling gradient 2 according to EN 50178
Protection IP20
Altitude max. 2000 m, above: reduction
Humidity 20% to 90% related humidity, non-condensing
Mounting vertical on a mounting panel
Connections
Input terminals 16 mm
2
25 mm
2
50 mm
2
Connection to the inverter 6,0 mm
2
10 mm
2
16 mm
2
Mains fuses max. 50 A 80 A 100 A
Grounding diameter 10 mm
2
10 mm
2
10 mm
2
General
Inductivity of choke 660 µH 330 µH 270 µH
Losses (ca.) 100 W 200 W 240 W
Weight of the filter 10 kg 16 kg 21 kg
Cooling forced
Material galvanized sheet steel
