COMPONENT IDENTIFICATION.
Legend:
1 Main switch.
Set to ON, the machine power is turned on and the LED (2) on the switch comes on.
Set to OFF, the machine power is turned off and the LED (2) on the switch goes off.
3 Cup heating plate switch.
Its operation is enabled when setting the switch (1) to ON.
Set to ON, the cup heating plate is turned on and the LED (4) on the switch comes on.
Set to OFF, the cup heating plate is turned off and the LED (4) on the switch goes off.
5 Heating element LED.
Indicates when the heating element to heat the water is on.
6 Steam tap.
7 Water tap.
8 Boiler pressure gauge.
9 Pump pressure gauge.
10 Cup heating plate.
11 Drip tray with grille.
12 Filter holder.
13 Coffee unit.
14 Selector knob.
