This output provides an excellent quality analogue video connection (connect to
the TV has no HDMI interface)
Analogue Stereo Audio Output
Connect the left/right audio cables to this output for analogue stereo sound.
Composite Video Output
This output is the most basic video connections and is Standard Definition only.
S-Video Output
This output offers a higher quality signal than composite for Compatible equipment
but is Standard Definition only.
DC Power Input
This input should be attached with the included 100-240V AC auto-ranging power
adaptor. See “Safety Warnings” before operating the unit.
2.4 Front Panel Display
