User Manual
Removing the C-CARD
Open the door and remove the C-CARD out of one of the two slots (as shown in
the right side of the previous picture).
CHART PLOTTER DIMENSIONS
329mm [13”]
211mm [8.3”]
160.2mm
[6.3”]
221mm [8.7”]
125mm [4.9”]
230.5mm [9.1”]
264mm (10.4”)
INSTALLATION AND REMOVING
VOUT
40mm
(1.6”)
140 (5.5”)
225mm [8.56”]
175mm [6.9”]
VOUT
