User Manual
The possible choices are listed in the table below:
Normal : It is recommended when the chart plotter is not exposed to the direct sunlight. When this mode
is set the maps are displayed in order to use colors as similar as possible to the ones used in the
original paper charts.
NOAA : Allows setting NOAA paper chart colors presentation.
Sunlight : It is designed to enhance the visibility of the screen when the chart plotter is exposed to the
sunlight. The maps are much brighter than in the other modes and the depth areas are filled with
white color so different depth areas are not easily distinguishable.
Night : It is recommended when the environment is dark in order to reduce the glare of the display. The
chart plotter displays maps and screen in darker colors.
Currents Prediction
[MENU] + "CURRENTS PREDICTION" + [ENTER]
A window is shown on the chart. It is possible to see the variation of the Tidal
arrows on the selected area at any given time. Press [ENTER] to set the date and
time manually, and dedicated keys to decrease time and to increase time.
4.2 OTHER MAP CONFIGURATIONS
[MENU] + "OTHER MAP CONFIGURATIONS" + [ENTER]
Allows the user to customize the following selections and is divided into the fol-
lowing setting menus: Marine Settings, Depth Settings, Land Settings, Chart Set-
tings and Underwater Objects Settings.
Display Mode
[MENU] + "OTHER MAP CONFIGURATIONS" + [ENTER] + "DISPLAY MODE"
+ [ENTER]
Selects from a pre-defined table what cartographic objects are displayed and
which display options are set. Pre-programmed settings are user selectable from
Full, Medium, Low, Radar, Tides, Custom.
The table below shows the selections for each mode:
Setting Full Medium Low Radar Tides Custom
(Default values)
Names On On On On On On
Name Tags On Off Off Off Off On
Nav Aids & Light Sectors On No Sector No Sector No Sector Off On
Attention Areas On On Off Off Off On
Tides & Currents On Off Off Off On On
Seabed Type On Off Off Off Off On
Ports & Services On On Off On Off On
Tracks & Routes On Off Off Off Off On
Depth Range Min 0 Mt 0 Mt 0 Mt 0 Mt 0 Mt 5 Mt
Depth Range Max 9999 Mt 9999 Mt 9999 Mt 9999 Mt 9999 Mt 20 Mt
Land Elevations On On Off Off Off Off
Land Elevation Values On Off Off Off Off On
Roads On Off Off Off Off Off
Points Of Interest On Off Off Off Off Off
Lat/Lon Grid On Off Off Off Off On
Chart Boundaries On Auto Off Off Off Auto
Value-Added Data On Off Off Off Off On
Chart Lock On On On On On On
Underwater Objects Limit 9999 Mt 10 Mt 10 Mt 10 Mt 10 Mt 3 Mt
Rocks Icon+Depth Icon Icon Icon Icon Icon
Obstructions Icon+Depth Icon Icon Icon Icon Icon
Diffusers Icon+Depth Icon Icon Icon Icon Icon
Wrecks Icon+Depth Icon Icon Icon Icon Icon
Marine Settings
To control the display on the map of the marine features.
