VDO MAP 7wi Plus GPS - External Wiring Diagrams

93
User Manual
TYPICAL CONNECTIONS
GPS Connection on Port 3 for MAP 7w Plus GPS
AUTOPILOT DEVICE
NMEA0183/180/180CDX/INPUT+
SIGNAL RETURN
FUNCTION
QUICK DISCONNECT BRACKET CABLE
DESCRIPTIONWIRE COLOR
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE
POWER SUPPLY GND
POWER SUPPLY+
NMEA0183/C-COM
SIGNAL RETURN
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
SIGNAL RETURN
POWER GND
POWER +10-35Vdc
INPUT1+
SIGNAL RETURN-
OUTPUT1+
INPUT2+
OUTPUT2+
INPUT3+
OUTPUT3+
SIGNAL RETURN-
FUNCTION
Autopilot Connection on Port 2
NMEA0183
DEVICE
NMEA0183 OUTPUT+
NMEA0183 INPUT+
SIGNAL RETURN
FUNCTION
QUICK DISCONNECT BRACKET CABLE
DESCRIPTIONWIRE COLOR
BLACK
RED
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLUE
POWER SUPPLY GND
POWER SUPPLY+
NMEA0183/C-COM
SIGNAL RETURN
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
NMEA0183/C-COM
NMEA0183/180/180CDX/C-COM
SIGNAL RETURN
POWER GND
POWER +10-35Vdc
INPUT1+
SIGNAL RETURN-
OUTPUT1+
INPUT2+
OUTPUT2+
INPUT3+
OUTPUT3+
SIGNAL RETURN-
FUNCTION
External NMEA Connection on Port 1
