Vega FIBERTRAC 31 User Manual

79
13 Supplement
FIBERTRAC 31 • Probus PA
43833-EN-170126
Output variable - Level measurement
Output
Ʋ Output signal digital output signal, format according to IEEE-754
Ʋ Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
Probus PA prole 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB Electronics temperature
Ʋ 3. FB Pulse rate
Current value
10 mA, ±0.5 mA
Output variable - Level detection
Output
Ʋ Output signal digital output signal, format according to IEEE-754
Ʋ Sensor address 126 (default setting)
Damping (63 % of the input variable) 0 … 999 s, adjustable
Probus PA prole 3.02
Number of FBs with AI (function blocks
with analogue input)
3
Default values
Ʋ 1. FB PV
Ʋ 2. FB Electronics temperature
Ʋ 3. FB Pulse rate
Current value
10 mA, ±0.5 mA
Relay output
Output Relay output (SPDT), oating spdt
Switching voltage
Ʋ Min. 10 mV
Ʋ Max. 253 V AC, 253 V DC
Switching current
Ʋ Min. 10 µA
Ʋ Max. 3 A AC, 1 A DC
Breaking capacity
Ʋ Min. 50 mW
Ʋ Max. 750 VA AC, 40 W DC
If inductive loads or stronger currents are switched
through, the gold plating on the relay contact surface will
be permanently damaged. The contact is then no longer
suitable for switching low-level signal circuits.
