13 Supplement
FIBERTRAC 31 • Probus PA
43833-EN-170126
Priority Description according to
Probusstandard
User Error Codes NE-107 status
23 Communication Error in
MGC
8 FAILURE
22 MGC-Slave reports Error 38 FAILURE
21 Undened 21 - -
20 Undened 20 - -
19 Undened 19 - -
18 Detector Temperature
critical
125 OUT_OF_SPEC
17 Error while Auto-Standard-
ization
73 FAILURE
16 Excessive Radiation 123, 124 FAILURE
15 Input out of Bounds 13 OUT_OF_SPEC
14 Error while Signal Pro-
cessing
68 FAILURE
13 Undened 13 - -
12 Undened 12 - -
11 Undened 11 - -
10 Undened 10 - -
9 Undened 9 - -
8 Undened 8 - -
7 AITB Simulated 29 FUNCTION CHECK
6 Undened 6 - -
5 Undened 5 - -
4 Undened 4 - -
3 Undened 3 - -
2 Undened 2 - -
1 Error while Trend Re-
cording
126, 127 GOOD
0 Undened 01 - -
Not displayed 33, 45, 71, 86 GOOD
Note:
The NE-107 status preset in the delivery status is only a recommen-
dation. You can adapt the settings according to PA prole 3.02. See
DIAG_EVENT_SWITCH.
13.3 Dimensions
The following dimensional drawings represent only an extract of all possible versions. Detailed
dimensional drawings can be downloaded at www.vega.com/downloads under "Drawings".
