17
4 Mounting
MINITRAC 31 • 4 … 20 mA/HART - four-wire
40447-EN-130430
3
2
1
Fig. 7: Mounting position - level detection
1 Mounting horizontal
2 Mounting vertical
3 Mounting horizontally, at right angles to container
Level measurement - Residue detection
The MINITRAC 31 can be used for residue detection, e.g. in storage
tanks for high-cost liquids. For this purpose, the instrument must be
mounted at the lowest point of the vessel.
