6 Set up with the display and adjustment module
MINITRAC 31 • 4 … 20 mA/HART - four-wire
40447-EN-130430
Themode'Standard',withxedaddress0(factorysetting),means
output of the measured value as 8/16 mA signal.
This parameter is described in the operating instructions manual
"Display and adjustment module".
With this function
•
Load parameter adjustment data from the sensor into the display
and adjustment module
•
Write parameter adjustment data from the display and adjustment
module into the sensor
This parameter is described in the operating instructions manual
"Display and adjustment module".
Info
Inthismenuyouwillndthefollowingmenuitems:
•
Instrument name - shows instrument name and serial number
•
Instrument version - shows hardware and software version of the
instrument
•
Date of manufacture - shows calibration date and the date of the
last change
•
Instrument features - shows further instrument features
These parameters are described in the operating instructions manual
"Display and adjustment module".
6.6 Parameter adjustment - X-ray alarm
X-rayradiation,forexample,causewithweldjointtestscaninuence
your measured values unnoticeably. Hence it is importnat to recog-
nizedinterferingX-rayradiation.
TheMINITRAC31recognizestheX-rayraditationandreactsfroman
individuallydenableraditiationvolume.
The level or density measuring instrument acts as Master and the
MINITRAC 31 operates as Slave.
Firstofall,denethefunctionoftheSlaveinstrumentbeforeyou
denetheMasterinstrument.TheMasterinstrumentcanthusimme-
diatelyrecognizetheconnectedSlave.
Forthispurpose,theSlaveinstrumentmustbedenedas"X-ray
alarm". Select under the menu item "Setup/Application" the function
"X-ray alarm".
You can set the address (MGC) on the Slave instrument at will. Only
the address "0 - 0" is reserved for the Master instrument.
Set the address setting (MGC) on the Master instrument to "0 - 0".
You have to enter the address of the Slave instrument in the list of
the Master instrument. This function is not possible in the display and
Additional adjustments/
Copy instrument settings
Inf
o
X-ray alarm
