6 Set up with the display and adjustment module
MINITRAC 31 • 4 … 20 mA/HART - four-wire
40447-EN-130430
Default settings: Resetting of the parameter adjustment like under
"Basic adjustment". In addition, special parameters will be reset to
defaultvalues.Order-specicsettingswillnotbedeleted.
Peak values measured value: Resetting of the parameter adjust-
ments in the menu item "Setup" to the default values of the respective
instrument.Order-specicsettingsremainbutarenottakenoverinto
the current parameters.
Peak values temperature: Resetting of the measured min. and max.
temperatures to the actual measured value.
The following table shows the default values of the instrument. The
values apply for the application "Level". First of all you have to select
the application.
Depending on the instrument version, not all menu items may be
availableortheymaybedierentlyassigned:
Menu Menu item Default value
Adjustment Measurement
loop name
Sensor
Isotope Cs-137
Applications Limit level
Adjustment mode Single point adjustment
Adjustment - un-
covered
90000 ct/s
Adjustment - cov-
ered
9000 ct/s
only with two-point adjustment
Delta I
90 %
Background ra-
diation
0 ct/s
Temperature unit °C
Damping Is calculated automatically by the in-
strument
Current output
mode
8/16 mA, < 3.6 mA
X-ray alarm Modulated measuring current
Mode - Relay
Overllprotection
Block operation Released
Display Language Selected language
Displayed value Pulse rate
Additional settings Temperature unit °C
HART mode Standard
With this function you can select the mode.
ThesensoroerstheHARTmodesstandardandmultidrop.
If the measured value is outputted via the 4 … 20 mA output, you
must not switch over to HART Multidrop.
Additional adjustments/
HART mode
