6 Set up with the display and adjustment module
MINITRAC 31 • 4 … 20 mA/HART - four-wire
40447-EN-130430
Additional settings
The following reset functions are available:
Basic adjustments: Resetting of the parameter adjustmetns to
defaultvaluesatthetimeofshipment.Order-specicsettingswillbe
deleted.
Default settings: Resetting of the parameter adjustment like under
"Basic adjustment". In addition, special parameters will be reset to
defaultvalues.Order-specicsettingswillnotbedeleted.
Peak values measured value: Resetting of the parameter adjust-
ments in the menu item "Setup" to the default values of the respective
instrument.Order-specicsettingsremainbutarenottakenoverinto
the current parameters.
Peak values temperature: Resetting of the measured min. and max.
temperatures to the actual measured value.
The following table shows the default values of the instrument. The
values apply for the application "Level". First of all you have to select
the application.
Depending on the instrument version, not all menu items may be
availableortheymaybedierentlyassigned:
Menu Menu item Default value
Adjustment Measurement loop name Sensor
Isotope Cs-137
Applications Level
Background radiation
0 ct/s
Unit of the process value m
Temperature unit
° C
Damping 60 s
Real value correction 0
Current output mode
4 … 20 mA, < 3.6 mA
Current output Min./Max. Min. current 3.8 mA, max. current 20.5 mA
X-ray alarm Modulated measuring current
Reference value - Relay None
Block operation Released
Display Language Selected language
Displayed value Pulse rate
Display unit ct/s
Additional settings Temperature unit °C
Linearizationcurve Empty
HART mode Standard
Address 0
Additional adjustments
- Reset
