Vega MINITRAC 31 Installation & Maintenance Instructions

76
11 Supplement
MINITRAC 31 • 4 … 20 mA/HART - four-wire
40447-EN-130430
Ambient conditions
Ambient, storage and transport tempera-
ture
-40 … +60 °C (-40 … +140 °F)
Process conditions
Fortheprocessconditions,pleasealsonotethespecicationsonthetypelabel.Thelowervalue
always applies.
Process pressure Unpressurized
Process temperature (measured on the
detector tube)
-40 … +60 °C (-40 … +140 °F)
With temperatures of more than 60 °C we recommend
the use of water cooling
Vibrationresistance
6)
mechanical vibrations up to 1 g in the frequency range
5…200Hz
Electromechanical data - version IP 66/IP 67
Cable entry
Ʋ M20 x 1.5 2 x cable gland M20 x 1.5 (cable: ø 6 … 12 mm), 4 x
blind plug M20 x 1.5
Included: 1 x cable gland M20 x 1.5
Ʋ ½ NPT 5 x closing cap (red) ½ NPT
Included: 3 x cable gland ½ NPT (cable: ø 6 … 12 mm),
4 x blind plug ½ NPT
Spring-loaded terminals for wire cross-section
Ʋ Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Display and adjustment module
Display element Display with backlight
Measured value indication
Ʋ Number of digits 5
Ʋ Sizeofdigits W x H = 7 x 13 mm
Adjustment elements 4 keys
Protection rating
Ʋ unassembled IP 20
Ʋ mounted into the housing without
cover
IP 40
Material
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Integrated clock
Date format Day.Month.Year
Time format
12 h/24 h
TimezoneExfactory CET
6)
Tested according to the guidelines of German Lloyd, GL directive 2.
