5
Mtr1
Mtr2
setj
setJ
Primary/SecondarySpeeds
(Input2)
Straightthroughcable
pins9and15notrequired
Optional Digital Joystick
TheoptionaldigitaljoystickallowsremotejogcontrolofaoneortwoaxisVXMcontroller.
ThejoystickprovidesfourmomentaryoutputsthatareconnectedtotheJogMotorinputs
ontheAuxiliaryI/O(internallyconnectedtosameinputsasthefrontpaneljogbuttons.)
Seepreviouspageforinformationonjog
functionandspeedsettings.
ThejoystickwithouttheenclosureisavailableforOEMapplications.
1.45"x5.75"x0.85"(WidthxDepthxHeight)
1.6"(bottomofenclosuretotopofjoysticklever)
ThedigitaljoystickhasabuttonswitchconnectedtoInput2fortogglingbetweenthe
primaryandsecondarysettablejog
speeds.
Thedefaultprimaryandsecondaryspeedsarebydefaultbothsetto2000.
Itispossibletodisable/removethebuttonswitchifInput2isneededforafunction
otherthanjogspeedselection. Todisable/removethebutton,withthebuttonintheout
position,useplierstopullthebuttoncap
offtheswitchactuator.Theswitchactuator
shouldnowbebelowthesurfaceenoughtopreventunintendedinput. Analternate
methodtodisablethebuttonswitchisbyclippingoffpin6onthecablesconnector.
Enclosure Dimensions:
Overall height:
NOTE:
NOTE:
ToVXMAuxiliaryI/O
+
+
