SeeAlso
Auxiliary I/O Connection (page 6)
OptionalAuxiliary I/O Breakout Module
TheoptionalauxiliaryI/Obreakoutmoduleisaconvenientmethodtointerfacetothe
VXMsauxiliaryI/O. Wireconnectionscanbemadetoall15I/Oconnectionsusingthe
screwtypeterminalblocks.
Wiresize: 26to18AWG
Bootmaterial:
PVC
Bootdielectricstrength: 700V/mil
Specifications
0.984"
1.738"
2.40"
1.30"
Ø0.120"
1(0V)
2(+5V)
3(Ain)
5
678910
11
15
14
13
12
4
Cablewith
all15through
Protective
Boot
WireAccessHole
Optional(2)
Pin# Name
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0V
+5V
Ain
Run
I1
I2
I3
I4
0V
J1-
J1+
J2-
J2+
O1
O2
