Motor Torque Curves
6
0
50
100
150
200
250
300
Torque(oz-in)
1 200 500 1000 2000 3000 4000 5000 6000
Speed
Speed
Slo-Syn M092 4.6A
0.5 1.25 2.5 5.0 7.5 10 12.5 15
rev/sec
steps/sec
(Torquemeasuredat100%powersettings)
20
40
60
80
100
120
140
160
180
Torque(oz-in)
1 200 500 1000 2000 3000 4000 5000 6000
Speed
Vexta
PK268-03
0.5 1.25 2.5 5.0 7.5 10 12.5 15
rev/sec
steps/sec
90
Vexta PK264-03
40
50
60
70
80
Torque(oz-in)
1 200 500 1000 2000 3000 4000 5000 6000
0.5 1.25 2.5 5.0 7.5 10 12.5 15
rev/sec
steps/sec
