6.5 Case External Dimensions
The dimensions of the VR2Tx case can be useful when designing a mooring plan or mooring equipment. The
dimensions, in inches, of the case are shown in the drawing below.
0.391”
diameter
attachment
hole
VR2Tx-69kHz
Dimensions are in inches
