VEMCO - VR2Tx Manual 15 March 2019 54
9.3 VR2Tx Specifications
Dimensions
308 mm (12.125") overall length x 73 mm (2.875") diameter
Weight
1190 g in air; 50 g in water
Receive Frequency
69.0 kHz
Operating temperature
-5°C to +40 °C; Water in which VR2Tx is deployed must not freeze.
Shipping & storage
temperature
-5°C to +50°C
Battery
1 - Tadiran TL-5930/F Lithium Inorganic battery or equivalent, 3.6 Volts
• Nominal capacity @ 4 mA, to 2 V 19 Ah
• Rated voltage 3.6 V
• Maximum recommended continuous current 230 mA
• Maximum pulse current capability 500 mA
• Weight 105 g (3.7 oz)
• Li metal content approx. 5 g
U.L. Component Recognition, MH 12193
Battery Life
Approximately 14 months (using Tadiran TL-5930/F)
Memory
16 MB Flash memory (~ 1.6 million detections)
32 MB Flash memory (~ 3 million detections)
Static depth rating
500 meters (730 psi)
Ingress Protection
IPX8 to rated depth
Bluetooth wireless
certifications
VR2Tx version:
Hardware ID: < 6
Hardware ID: > 6
Bluetooth ID:
B012394
D028756
FCC ID:
ED9LMX9838
A8TBM78ABCDEFGH
Industry Canada ID:
IC-1520A-LMX9838
12246A-BM78SPPS5M2
Software
Latest VEMCO User Environment (VUE) software
Attachment:
Standard method: 5 non-reusable lashing cable ties, 388 mm (15.25")
long, 7.5 mm (0.3") wide, UV protected, 120 lbs. tensile strength (VEMCO
number HWE 507450).
WARNING
The VR2Tx pressure case and seal have a static depth rating of
500 meters (730 psi).
Physical shocks to the receiver, such as bumping into a solid object, when it is at any depth
can result in a considerably higher pressure on the casing than just the depth pressure and
water may enter the VR2Tx case. If the O-rings or their mating surfaces are dirty or damaged,
then water may also enter the receiver case. If you are suspicious that water has entered the
receiver, then follow the suggestions in the Appendix for troubleshooting a pressurized case.
