- 14 -
Hood Installation
Appendix C
Hood Installation And Rigging (ERV500e ONLY)
Rigging
Screw: #10 x 3/4
Detail "A"
Detail "B"
Female
M
ale
B
lack
Male
Female
White
White
Black
See Detail "B"
See Detail "A"
SPREADER BARS
NOTE:
Remove all packaging before beginning to
rig the unit onto the installed roofcurb.
