Venmar ERV500e - Appendix D: Minimum Distance Requirements and Typical Installation

- 15 -
D-1: ERV500i - Minimum Distance Requirements
D-2: ERV500e - Typical Installation
Exhaust Air
From Space
Flow Measuring
Station (FMS)
Balancing
Damper
Flexible Duct
Connection
Exhaust Air
To Outside
Supply Air
From Outside
Supply Air
To Space
Min. 36"
[914mm]
Min. 36"
[914mm]
M
in. 36"
[914mm]
Min. 12"
[
305mm]
Exhaust
Air
Return
Air
Roofcurb
Supply
Air
Supply
Air
Appendix D
Minimum Distance Requirements And Typical Installation
